Home > Klein Tools KT4802 Parallel-Jaw Grip .70 - 1.25 Inch for ACSR Cable
Model#: 4802
Stock#: KT-KT4802
UPC/GTIN/EIN: 092644477584
Klein Tools KT4802 Parallel-Jaw Grip .70 - 1.25 Inch for ACSR Cable
KT-KT4802
$399.99 Sale price: $399.99
THIS ITEM SHIPS FOR FREE!
ON BACKORDER
Call for availability
Klein Tools KT4802 Parallel-Jaw Grip .70 - 1.0 Inch for ACSR Cable
The Klein Tools 4802 Series Parallel-Jaw Grip offers a 5-1/8" jaw length. Designed with a round inside-jaw contour for maximum contact to minimize conductor damage. Lower jaw is serrated to firmly grip insulated cables and conductors. Design includes a latch that prevents the grip from falling in case of jaw disengagement from the cable. Large-diameter eye accommodates large hooks on hoists, winches and tackle blocks. Klein Tools offers a lifetime guarantee on material defects and workmanship for the normal life of this product.
Specifications:
- Round jaw
- Maximum safe load of 12,000 lbs. (5443 kg)
- Maximum cable size of 1.25” and a minimum of 0.700”
- Jaw Length: 5-1/8'' (130 mm)
- Maximum Cable: 1.25'' (31.8 mm)
- Minimum Cable: .700'' (17.8 mm)
- Weight: 9 lb
Other Available Grips:
| Type | Part Number | Diameter | Cable Type | Max Safe Load |
|---|---|---|---|---|
| Haven's Grip | 1604-20L | .125" - .5" | Messenger, Guy Strand | 5000 lbs |
| Haven's Grip | 1625-20 | .28" - .75" | Wire Rope | 8000 lbs |
| Chicago Grip | 1613-40 | .12" - .37" | Aircraft, EHS, Messenger, Guy Strand | 4500 lbs |
| Chicago Grip | 1628-18 | .75" - 1.0" | Aircraft, EHS, Messenger, Guy Strand | 15,000 lbs |
| Chicago Grip | 1628-17 | .50" - .75" | Aircraft, EHS, Messenger, Guy Strand | 15,000 lbs |
| Chicago Grip | 1628-16 | .31" - .62" | Aircraft, EHS, Messenger, Guy Strand | 15,000 lbs |
| Chicago Grip | 1684-5C | .218" - .55" | Aircraft, EHS, Messenger, Guy Strand | 8000 lbs |
| Parallel-Jaw Grip | 1685-20 | .157" - .875" | Messenger, EHS, Coated | 4500 lbs |
| Parallel-Jaw Grip | 1685-31 | .625" - 1.25" | Messenger, EHS, Guy Strand | 7500 lbs |
| Chicago Grip | 1613-35 | #8 AWG Bare Copper - #6 AWG Bare Copper | Copper | 4500 lbs |
| Parallel-Jaw Grip with Hot Latch | KT4602 | .30" - .80" | ACSR | 10,000 lbs |
| Chicago Grip | 1684-5 | .218" - .55" | Aircraft, EHS, Messenger, Guy Strand | 8000 lbs |
| Chicago Grip | 1692-5 | .218" - .55" | Aircraft, EHS, Messenger, Guy Strand | 8000 lbs |
| Haven's Grip | 1625-20 1 | .50" - 1.0" | Wire Rope | 8000 lbs |
| Chicago Grip with Curved Jaw-Grip | 1684-74 | .218" - .55" | Aircraft, EHS, Messenger, Guy Strand | 8000 lbs |
| Chicago Grip | 1684-5F | .16" - .55" | Aircraft, EHS, Messenger, Guy Strand | 8000 lbs |
| Haven's Grip | 1625-20-7/8 | .38" - .88" | Wire Rope | 8000 lbs |
| Parallel Jaw Grip with Hot Latch | KT4802 | .70" - 1.25" | ACSR | 12,000 lbs |
| Chicago Grip with Hot-Line Latch | 1684-5H | .218" - .55" | Aircraft, EHS, Messenger, Guy Strand | 8000 lbs |
KT-KT4802
| Country of Manufacture: | United States |
| Manufacturer: | Klein Tools |
| Weight: | 8.98 |
